PRODUCT DETAILS
IP65 RGBW DMX Pixel String Lights with App Control
Chengyi Lighting’s IP65 RGBW pixel string lights combine individually programmable red, green, blue and true-white output in one pixel system. App-based point-to-point control enables running, chasing and custom dynamic patterns for commercial façades, rooflines, building outlines and event installations.
This product is the RGBW app-control option in our DMX512 string lights collection. The listed standard configuration is 10 m with 100 LEDs. Custom 20 m, 50 m and 100 m project lengths are available, with quick-plug end-to-end connection supporting runs up to 100 m when the power and control layout is correctly engineered.
Product Highlights
- RGBW 4-in-1 pixels: Each point combines RGB colour mixing with a dedicated white channel for richer effects and cleaner white output.
- Point-to-point app control: Programme individual pixels for running, chasing, gradient and custom patterns, with eight built-in modes listed for quick setup.
- DMX-capable project architecture: The EN-408 technical data lists standard and extensible DMX512 modes for professional controller integration.
- IP65 sealed construction: Injection-moulded joints and sealed pixel beads are designed for exterior decorative installations.
- H03RN-F rubber cable: The listed 1 × 0.5 mm² black rubber main line supports heavy-duty commercial use and repeated installation.
- Long linkable runs: Pixel quick-plug connections can form project-configured runs up to 100 m, subject to controller capacity and power-distribution design.
Technical Specifications
| Listed Model Configuration | 10 m / 100 LEDs |
|---|---|
| Available Lengths | 10 m, 20 m, 50 m and 100 m customizable |
| Light Source | RGBW 4-in-1 individually programmable LED pixels |
| Listed Power | 10 W |
| Input Voltage Options | AC 110V / 220V / 240V or DC 24V listed; final configuration must be confirmed before production |
| Control | App control and remote control; point-to-point dynamic patterns and eight built-in modes |
| DMX Controller Support | EN-408 documentation lists standard DMX512 and extensible DMX modes |
| Cable | H03RN-F 1 × 0.5 mm² black rubber pixel wire |
| Connection | End-to-end pixel quick plugs; up to 100 m linkable when engineered for the project |
| IP Rating | IP65 sealed outdoor weatherproof construction |
| CRI | Ra 90 listed |
| Luminous Flux | 700 lm listed |
| Rated Life | 50,000 hours listed |
| Working Temperature | -45°C to 60°C listed |
| Warranty | 2 years listed |
| Certifications | EMC, RoHS, LVD and CE listed |
| MOQ | 5 pieces |
RGBW and DMX Control Planning
The standard smart configuration uses app and remote control for individual pixel programming. For installations requiring centralized show control, the listed EN-408 system supports eight TTL/RS-485 output ports and includes standard or extensible DMX modes. Chengyi Lighting should confirm pixel protocol, channel count, controller model, voltage, power injection and signal topology against the approved layout before production.
Applications
- Commercial façade and building-outline lighting
- Rooflines, eaves and permanent architectural accents
- Shopping centres, hotels and entertainment venues
- Christmas, New Year and seasonal installations
- Concerts, stages and branded event displays
- Outdoor gardens, plazas and public-space projects
OEM and Project Customization
Available options include 10–100 m project lengths, pixel spacing, RGBW effects, control method, input voltage, IP configuration, cable colour and thickness, light-cover shape, plug standard, custom programming, OEM branding and export packaging. Visit our outdoor decorative lighting product centre or contact Chengyi Lighting with drawings, total length, installation voltage and required effects for a B2B quotation.
